Bakers Pride APC-18 Specifications

Questions???
Call 253-853-7462





CONVEYOR OVENS SERIES

STANDARD EQUIPMENT
  • 18" Wide Conveyor Belt
  • 36" Long Baking Chamber
  • Separate Top and Bottom Heat Controls
  • Digital Electronic Temperature Control
  • Conveyor Speed Control with Constant Speed Circuitry
  • Bake times range from 1.5 to 30 minutes
  • Removable Crumb Trays on Both Ends of oven
  • Entry and Exit Opening Height Adjustable up to 4 1/2"
  • All Stainless Steel Sides and Top
  • 4" Adjustable Legs (for Single or Double unit only)
  • Stand with Adjustable Legs (Standard with APC-18-3)

FEATURES

  • Ultra quiet operation - no blower motor or fans
  • Digital electronic thermostat has a maximum temperature of 800° F. Displays actual oven temperatures. May be set to display i either Fahrenheit or Celsius degrees.
  • Top and bottom heat are independently controlled. This allows the user to vary the wattage of the heating elements in order to achieve the desired degree of baking or browning.
  • Computerized conveyor speed control with digital display provides uniform cook time even when the load on the conveyor belt varies, or voltage fluctuations occur. Cook time from 1.5 to 30 minutes. Other speed ranges may be specified when ordered.
  • Stackable two high or three high
  • Applicable for various menu items including but not limited to: appetizers, biscuits, cookies, Mexican or Italian entrees, fish, sandwiches, pizza, pretzels and pita bread. This oven may be used for most baking, reheating or finishing off applications.
  • Solidly built with heavy gauge aluminized steel and all stainless steel sides and top.
  • ONE YEAR parts and labor Limited Warranty.
  • LISTINGS and CERTIFICATIONS:
    Each oven shall be U.L. listed (US only) CSA Certified (Canada Only), CE Certified (Europe only) and NSF International Certified.


Model APC-18-1



OPTIONS:
  • Belt Direction
    • Unloading opposite control side
  • Product Stop
  • Entry Tray
  • Exit Tray
  • Stand (gray painted) APC-18-1
  • Stand (gray painted) APC-18-2
  • Casters on stand
  • Special voltages available upon request.

NOTE: When stacked, each oven requires a separate electrical connection.

Model Volts Watts Phase/Hz Amperes
L1
Amperes
L2
Amperes
L3
Amperes
Neutral
Carton
Size
Shipping
Weight
APC-18-1 115/208 10KW 3-50/60 26.0 33.5 25.00 1 42.0 Cu Ft 383 Lbs
115/240 22.7 29.0 21.7 1
115/208 1-50/60 49.0 48.0 - 1
115/240 46.5 45.5 - 1



NOTE: For best pizza baking results the use of seasoned screens and black coated pans is highly recommended. Uncoated shiny aluminum pans should not be used.
Minimum
Clearance
Combustible
Construction
Non-Combustible
Construction
Left 3" 3"
Right 3" 3"
Back 18" 18"

APPROXIMATE PIZZA PRODUCTION PER HOUR - APC-18-1

Pan/Screen
Diameter
Bake Time In Minutes
Inches 4 5 6 7 8 9 10 11 12
6" 255 204 169 145 127 113 102 92 84
8" 135 108 90 77 67 60 54 49 45
10" 82 66 54 47 41 36 33 30 27
12" 45 36 30 25 22 19 18 16 13
14" 37 30 24 21 18 16 15 13 12
16" 30 24 20 17 15 13 12 11 10
18" 30 24 20 17 15 13 12 11 10
